| AC Input |
Below 10KVA: Single-phase 110VAC or 220VAC ± 10%; 50Hz ± 50Hz
Above 10KVA: three-phase 380VAC ± 10%; Three phase four wire+ground wire; 50Hz ± 50Hz |
| AC Output |
Low grade 1.0~150.0VAC, high grade 150.1~300.0VAC |
| output frequency |
Below 20KVA: 45-400Hz, adjustable; Above 20KVA: 45-65Hz, adjustable.
Adjust the stride of 0.1Hz, shortcut keys: 50Hz, 60Hz |
| frequency stability |
≤0.1% |
| voltage stability |
≤1% |
| degree of distortion |
≤2%(THD) |
| Source voltage effect |
≤1% |
| Load effect |
≤1% |
| Efficiency |
≥90% |
| Frequency display |
0.1% readings, with a resolution of 0.1Hz |
| Voltage display |
± (0.5% reading + 0.5% range), resolution of 0.1V |
| Current Display |
± (0.5% reading + 0.5% range), resolution 0.001A/0.1A |
| Power display |
± (0.5% reading + 0.5% range), resolution 0.01W/0.1KW |
| The power factor display |
± 0.1 with a resolution of 0.01 |
| Preset function |
Output voltage, output frequency, output current upper limit / communication address |
| Shortcuts function |
Common voltage, frequency conversion, M1 M2 M3 three groups of shortcut group storage |
| Alarm function |
Send an alarm (sound and light) signal to display the fault code |
| overload capacity |
1.0 Ie / 1.1 Ie |
| overheat protection |
Power device temperature is greater than 85℃ ± 5℃ |
| External communication interface (optional) |
Standard with MODBUS RTU communication protocol, upper computer software. RS-232C (standard) / RS485 (optional). |
| Case protection grade |
IP20 |
| Case structure |
Cabinet-type (with casters) |
| work environment |
Temperature: -10℃ ~ 40℃ Humidity: 10%~90% (25℃ without condensation), with an altitude of 2km |
