How to Use a DC Power Supply
Product Gallery
Why Choose Us?
As long as you purchase our product, we will provide you with lifelong service!
The product warranty period is 1 year from the date of purchase.
If you encounter problems, we provide free remote support testing and supply replacement components (free within the first year).
Free components are provided for maintenance; you only need to cover a small shipping cost.
Specifications
| Working Voltage |
AC220V±10% 50HZ |
| Working Conditions |
Temperature 0 ~ 40℃, Relative humidity: ≤80%RH |
| Storage Conditions |
Temperature -20 ~ 60℃, Relative humidity: ≤80%RH |
| Accuracy Temperature Range |
23℃±5℃ |
| Load Regulation |
≤0.1%+5mV |
| Line Regulation |
≤0.01%+5mV |
| Display Resolution |
10mV |
| Setting Precision |
≤0.1%+1 digits |
| Readback Value Resolution |
10mV |
| Reading Accuracy |
≤0.1%+1 digits |
| Ripple & Noise |
10mVrms |
| Load Regulation |
≤0.2%+3mA |
| Line Regulation |
≤0.2%+3mA |
| Display Resolution |
1mA |
| Setting Precision |
≤0.2%+3mA |
| Readback Value Resolution |
1mA |
| Reading Accuracy |
≤0.2%+3digits |
| Ripple & Noise |
8mVrms |
| OVP (Over Voltage Protection) |
0-Vmax±0.2%FS |
| Max Voltage |
Vmax±0.2% |
| OCP (Over Current Protection) |
0-Cmax±0.2%FS |
| Max Current |
Cmax±0.2% |
| Heat-Dissipating Method |
Air-cooled |
| Weight |
1.95KG |
| Size (Bare Unit) |
80*150*230 MM |
Product Models
| Model |
Voltage Range |
Current Range |
Display Type |
| MY-K3005MF |
0-30V |
0-5A |
4 LED Digital |
| MY-K3010MF |
0-30V |
0-10A |
4 LED Digital |
| MY-K6005MF |
0-60V |
0-5A |
4 LED Digital |
Product Classification
Our Certificates
Exhibitions
Packaging & Transportation
Frequently Asked Questions
Q1
What Is A Variable DC Power Supply?
Re: It is a power source with an output voltage that the user can vary. Our variable DC power supplies allow you to change the voltage and the current to the Device Under Test (DUT).
Q2
Why Is A DC Power Source Needed?
Re: A DC power source provides a constant biasing voltage or current to electrical devices, components, or circuits and ensures that the DUT operates as expected.
Q3
How Do You Use A DC Power Source?
Re: A DC power source connects to a DUT via leads that connect to the DC power supply panel. Engineers can set voltages or current levels to power the device for testing purposes.
Q4
What Is A Bench DC Power Supply?
Re: A bench DC power supply is designed to sit on an engineer’s bench. It typically features a large, legible display and an intuitive user interface, allowing easy control of the supply from the front panel. Modern bench power supplies can also be controlled via software. The output terminals are easily accessible from the front, making them highly practical for testing circuits on the fly.
Q5
How Does A DC Power Source Work?
Re: A DC power source converts alternating current (AC) power into DC power using either a linear or switching methodology. A switching power supply offers higher efficiency, reduced weight, and a smaller overall size.
Q6
What are the dimensions and weight of these DC power supplies?
Re: The physical dimensions of the bare unit are 80*150*230 MM, and it has a net weight of approximately 1.95 KG, making it compact and lightweight for bench use.
