MYAMI Ac Dc Regulated 30V 5A 150W Linear Digital Tube Programmable Variable Adjustable Dc Power Supply

Send Inquiry

Product Description

MYAMI AC DC Regulated 30V 5A 150W Linear Digital Tube Programmable Variable Adjustable DC Power Supply

✓ Low noise and low ripple

✓ Power display

✓ Automatic carry of the decimal point

✓ Rear RS232/485/USB, upper computer software control (optional)

✓ Over voltage, over current, over power, over temperature, short circuit five powerful protection functions

✓ Long-term full load, short circuit ignition arc drawing machine

✓ Unique sunflower cooling function (linear power supply)

✓ High quality pure copper ring transformer (linear power supply)

✓ Intelligent temperature control fan

Specification

Model	MY-L3003P	MY-L3005P	MY-L6003P	MY-L6005P	MY-L15001P
Voltage	0 ~ 30V	0 ~ 30V	0 ~ 60V	0 ~ 60V	0 ~ 150V
Current	0 ~ 3A	0 ~ 5A	0 ~ 3A	0 ~ 5A	0 ~ 1A
Line Regulation
Voltage	≤0.1%+3mV	≤0.1%+3mV	≤0.1%+3mV	≤0.1%+3mV	≤0.1%+3mV
Current	≤0.01%+3mA	≤0.01%+3mA	≤0.01%+3mA	≤0.01%+3mA	≤0.01%+3mA
Load Regulation
Voltage	≤0.1%+2mV	≤0.1%+2mV	≤0.1%+2mV	≤0.1%+2mV	≤0.1%+2mV
Current	≤0.01%+5mA	≤0.01%+10mA	≤0.01%+5mA	≤0.01%+10mA	≤0.01%+5mA
Ripple & Noise
Voltage	≤1mVrms	≤2mVrms	≤2mVrms	≤2mVrms	≤1mVrms
Current	≤3mArms	≤3mArms	≤3mArms	≤3mArms	≤3mArms
Display
Voltage	10mV
Current	1mA
Readback value resolution
Voltage	10mV
Current	1mA
Operating environment (for indoor use)
Elevation	≤2000m
Temperature	-10℃ ~ 40℃
Humidity	≤80%
Storage environment
Temperature	-20℃ ~ 80℃
Humidity	≤80%
Power input	AC110V/AC220V±10%, 50/60Hz
Size
Fuselage size	280(D)×130(W)×165(H)mm
Package size	355(D)×178(W)×210(H)mm

Product Details

Product Classification

Company Profile

Our Certificate

Exhibition

Packaging & Transportation

Frequently Asked Questions

❓ Q1: What's the MOQ?

Re: The MOQ of machinery is 1 set.

❓ Q2: What's delivery time?

Re: The general delivery time is 3~5 days after order confirmed, it depends on the order quantity.

❓ Q3: Can you send the video to show how the machine works?

Re: Certainly, we have video of every machine, please feel free to contact us, we will send you machine video.

❓ Q4: What's your payment terms?

Re: 100% before shipment.

❓ Q5: What's the payment method?

Re: We accept T/T and L/C payment.

❓ Q6: What built-in protection features does the DC power supply have?

Re: It is equipped with five powerful protection functions: over voltage, over current, over power, over temperature, and short circuit protection.
