Product Description

MY-L6005P 30V 60V 3A 5A 150V 1A Linear Power Supply 150W 300W Low Frequency DC Stabilized Power Supply
  • Low noise and low ripple: Delivers exceptionally clean output for sensitive testing environments.
  • Power display: Offers clear and real-time visualization of power parameters.
  • Automatic carry of the decimal point: Enhances resolution and reading accuracy automatically.
  • Interface connectivity: Rear RS232/485/USB with upper computer software control support (optional).
  • Comprehensive protection: Features five powerful protection functions: over voltage, over current, over power, over temperature, and short circuit.
  • Heavy-duty capability: Designed for long-term full load operation and supports short circuit ignition arc drawing.
  • Unique sunflower cooling function: Specialized heat dissipation structure optimized for linear power supplies.
  • High-quality pure copper ring transformer: Built with premium materials to ensure durability and high efficiency.
  • Intelligent temperature control fan: Adjusts speed automatically based on load temperature for quiet operation.
Specification
Model MY-L3003P MY-L3005P MY-L6003P MY-L6005P MY-L15001P
Voltage 0~30V 0~30V 0~60V 0~60V 0~150V
Current 0~3A 0~5A 0~3A 0~5A 0~1A
Line Regulation
Voltage ≤0.1%+3mV ≤0.1%+3mV ≤0.1%+3mV ≤0.1%+3mV ≤0.1%+3mV
Current ≤0.01%+3mA ≤0.01%+3mA ≤0.01%+3mA ≤0.01%+3mA ≤0.01%+3mA
Load Regulation
Voltage ≤0.1%+2mV ≤0.1%+2mV ≤0.1%+2mV ≤0.1%+2mV ≤0.1%+2mV
Current ≤0.01%+5mA ≤0.01%+10mA ≤0.01%+5mA ≤0.01%+10mA ≤0.01%+5mA
Ripple & Noise
Voltage ≤1mVrms ≤2mVrms ≤2mVrms ≤2mVrms ≤1mVrms
Current ≤3mArms ≤3mArms ≤3mArms ≤3mArms ≤3mArms
Display
Voltage 10mV
Current 1mA
Readback Value Resolution
Voltage 10mV
Current 1mA
Operating Environment (for indoor use)
Elevation ≤2000m
Temperature -10°C ~ 40°C
Humidity ≤80%
Storage Environment
Temperature -20°C ~ 80°C
Humidity ≤80%
Power Input AC220V±10%, 50/60Hz
Size Information
Size 280(D)×130(W)×165(H)mm
Package Size 355(D)×178(W)×210(H)mm
Product Details
Product Details Main
Product View 1 Product View 2 Product View 3 Product View 4 Product View 5
Product Classification
Product Classification Chart
Company Profile
Company Facility and Profile
Our Certificate
Compliance Certificates
Exhibition
Exhibition History
Packaging & Transportation
Packaging and Shipping Options
FAQ Overview
FAQ Details Display
What is the Minimum Order Quantity (MOQ)?
The MOQ for machinery is 1 set.
What is the estimated delivery time?
The general delivery time is 3 to 5 days after the order is confirmed, depending on the overall order quantity.
Can you provide video demonstrations of the machine operating?
Yes, video presentations showing the performance of our machines are available. Please contact us to receive them.
What are your standard payment terms?
We require 100% payment prior to shipment.
What payment methods do you support?
We accept T/T (Telegraphic Transfer) and L/C (Letter of Credit) payment methods.
What safety protections are integrated into this linear power supply series?
This series includes five built-in protection capabilities: over voltage protection, over current protection, over power protection, over temperature protection, and short circuit protection.
