| Product Parameter | |||
|---|---|---|---|
| Model | HTB-2020 | HTB-2060 | HTB-2060 (external version) |
| Applicable environment for instruments | 1. Temperature : 0~40℃ 2. Use height : use within 2 Km altitude 3. Relative humidity: 40-80% humidity |
||
| Measuring Range | |||
| 1. Battery voltage measurement range | 0~20.000V Minimum resolution of 0.001V |
0~80.000V Minimum resolution of 0.001V |
- |
| 2. Overcurrent measurement range | 0-10.000A Minimum resolution of 0.001A |
0~20.000A Minimum resolution of 0.001A |
- |
| 3. Internal resistance measurement range | 0~999.0mΩ Minimum resolution of 0.1mΩ |
||
| 4. Identify the resistance measurement range | 0.1~999.9KΩ Minimum resolution of 0.1 KΩ |
||
| 5. Capacity measurement range | 0~100.0AH Minimum resolution of 0.1 mAH |
||
| Test Speed | |||
| 1. Static test (test all functions) | 1.1~2 Seconds | ||
| 2. Capacity test (1C current charge and discharge) | 3 to 4 hours (depending on the different battery) | ||
| Certainty of Measurement | |||
| 1. Voltage measurement accuracy | ± (Result 0.5% + 3 mV) | ||
| 2. Precision of current measurement | ± (Result 0.5% + 5 mA) | ||
| 3. Accuracy of internal resistance measurement | ± (Result : 1% + 1 mΩ) | ||
| 4. Identify the resistance measurement accuracy | 10KΩ±1% | ||
| 5. Accuracy of battery capacity measurement | 10AH±2% | ||
| Internal CNC DC Power Supply Index | |||
| 1. Maximum output voltage | 20V | 60V | - |
| 2. Maximum output current | 2A | 5A | - |
| Voltage Source Index | |||
| (1) Maximum output power | 40W | 200W | - |
| Internal CNC Electronic Load Index | |||
| (1) Maximum discharge voltage | 20V | 60V | - |
| (2) Maximum discharge current | 5A | 10A | - |
| (3) Limit power | 50W | 200W | - |
| 5. Wire voltage | <20mV | ||
| 6. Load adjustment rate | <10% | ||
| 7. Response time | 1S | ||
