| Mode | WS30 |
| Display method | 5-inch IPS industrial-grade liquid-crystal touch-screen |
| Display form | Real-time list values, real-time bar charts, real-time line charts |
| Record query | Analyzed and queried through dedicated computer software |
| Number of Channels | 10CH |
| Thermocouple Types | K, J, E, T, N, S, R, B |
| Accuracy | ±0.2°C plus 2 characters (excluding thermocouple error) |
| Measurement range | -200 to 1820 degrees Celsius (subject to thermocouple calibration range) |
| Cold-end compensation | Accuracy: ±0.5°C |
| Resolution | 0.01°C |
| Number of documents | Twenty (loop records) |
| File capacity | One file can record up to 200,000 sets of data (independent of channel count) |
| Recording duration | Total recording duration = recording interval × 46.29 days |
| Sampling speed | 100mS per channel |
| Isolation between Channels | Measurement of live 350V high-voltage AC / DC |
| Alarm sound | Available (sounds when trigger limits are exceeded, can be muted) |
| Recording interval | Configurable from 1 to 300 seconds |
| Communication interface | Standard USB |
| Power supply | DC 5V, < 2W |
| Standard Thermocouple | Each channel is equipped with a 2-meter K-type thermocouple |
| Size | 195.0mm x 127.0mm x 41.0mm |
| Weight | About 1.5Kg |
| Environmental conditions | 5 to 40 degrees Celsius, 20% to 80% relative humidity (non-condensing) |
