| Oscillation frequency | ×1 Range: 10Hz-100Hz |
| ×10 Range: 100Hz-1KHz | |
| ×100 Range: 1KHz-10KHz | |
| ×1K Range: 10KHz-100KHz | |
| ×10K Range: 100KHz-1MHz | |
| Frequency accuracy | ±3%+1Hz |
| Output impedance | 600Ω |
| Output attenuator | 0dB, 10 dB, 20 dB, 30 dB, 40 dB, 50 dB |
| Sinusoidal characteristic | Output voltage: 5V~6V |
| Frequency response: 10Hz~1MHz (±0.5dB) | |
| Distortion: 400Hz~20KHz (≤0.1%) | |
| Distortion: 100Hz~100KHz (≤0.3%) | |
| Distortion: 50Hz~200KHz (≤0.5%) | |
| Distortion: 20Hz~500KHz (≤1%) | |
| Distortion: 10Hz~1KHz (≤1.5%) | |
| Square wave characteristic | Output voltage: ≥10Vp-p |
| Up/down time: 0.5μs | |
| Duty cycle: 45:55:00 | |
| Synchronization range: ≤1%Vrms | |
| Input pressure limit: 15V | |
| Power | AC220V/110V±10% 50Hz/60Hz |
| Size | 239×140×200mm |
| Weight | 2.5Kg |
