| Parameter Block | Specification Details | |
|---|---|---|
| Oscillation Frequency | ×1 Range | 10Hz - 100Hz |
| ×10 Range | 100Hz - 1KHz | |
| ×100 Range | 1KHz - 10KHz | |
| ×1K Range | 10KHz - 100KHz | |
| ×10K Range | 100KHz - 1MHz | |
| Frequency Accuracy | ±3% + 1Hz | |
| Output Impedance | 600Ω | |
| Output Attenuator | 0dB, 10dB, 20dB, 30dB, 40dB, 50dB | |
| Sinusoidal Characteristic | Output Voltage | 5V ~ 6V |
| Frequency Response | 10Hz ~ 1MHz: ±0.5dB | |
| Distortion | 400Hz ~ 20KHz: ≤0.1% | |
| 100Hz ~ 100KHz: ≤0.3% | ||
| 50Hz ~ 200KHz: ≤0.5% | ||
| 20Hz ~ 500KHz: ≤1% | ||
| 10Hz ~ 1KHz: ≤1.5% | ||
| Square Wave Characteristic | Output Voltage | ≥10Vp-p |
| Up/down Time | 0.5μs | |
| Duty Cycle | 45:55:00 | |
| Synchronization Range | ≤1% Vrms | |
| Input Pressure Limit | 15V | |
| Power | AC 220V/110V ±10% 50Hz/60Hz | |
| Size | 239 × 140 × 200mm | |
| Weight | 2.5Kg | |
