Product Description

20MHz Analogue Oscilloscope Portable Analog Dual Channel Oscilloscope
Key Features
✓
Bandwidth: 20MHz
✓
Rise Time: <=17.5ns
✓
Deflection Factor: 5mv/DIV~20V/DIV 12 steps in 1-2-5 sequence Extended x5 to 1mv
✓
Vertical Mode: CH1, CH2, ALT, CHOP, ADD
✓
Sweep Time: 0.2uS/DIV-0.5s/DIV 20 steps in 1-2-5 sequence
✓
Trigger Mode: INT, EXT, ALT, LINE, TV-V, TV-H, LOCK
✓
Sweep Mode: AUTO, NORM, MAGx10
✓
Dimension (mm): 310(W) * 150(H) * 455(D)
✓
Weight: 8kg
✓
Useful Screen Area: 8x10DIV (1DIV=10mm)
Specifications
Parameter Item Specification Details
Frequency Range DC-20MHz
On Screen Grid 8*10div (1div=1cm)
Vertical Deflection Display Mode CH1 CH2 CH3 ADD ALT CHOP
Deflection Factor 5mV/div to 5V/div ±3% (1mV/div ±5%)
Rise Time ≤17.5ns / ≤17.2ns
Polarity Selection ±CH2
Max Input Voltage 250V (≤1KHz)
Horizontal Bias Display Mode 1, 10, X-Y
Time Base 0.2us/div ~ 0.2s/div
Sweep Width ×10
Accuracy 3%
Correction Waveform Frequency 1KHz 20% Voltage: 0.5V 1%
Input Impedance 1MΩ
Size 450 × 310 × 150mm
Weight 8Kg
