| Frequency range | DC-40MHz | |
| On screen grid | 8*10div(1div=1cm) | |
| Vertical deflection | Display mode | CH1 CH2 CH3 ADD ALT CHOP |
| Deflection factor | 5mV/div to 5V/div±3%(1mV/div±5%) | |
| Rise time | ≤17.5ns (≤17.2ns) | |
| Polarity selection | ±CH2 | |
| Max input voltage | 250V (≤1KHz) | |
| Horizontal bias | Display mode | 1, 10, X-Y |
| Time base | 0.2us/div~0.2s/div | |
| Sweep width | ×10 | |
| Accuracy | 3% | |
| Correction waveform | Frequency 1KHz 20% Voltage:0.5V 1% | |
| Input impedance | 1MΩ | |
| Size | 450×310×150mm | |
| Weight | 8Kg | |
