| Parameters | Details & Limits | |
|---|---|---|
| Frequency Range | DC-20MHz | |
| On Screen Grid | 8*10 div (1 div = 1cm) | |
| Vertical Deflection - Display Mode | CH1, CH2, CH3, ADD, ALT, CHOP | |
| Vertical Deflection - Factor | 5mV/div to 5V/div ±3% (1mV/div ±5%) | |
| Vertical Deflection - Rise Time | ≤17.5ns (≤17.2ns max parameter) | |
| Vertical Deflection - Polarity | ±CH2 | |
| Max Input Voltage | 250V (≤1KHz) | |
| Horizontal Bias - Display Mode | 1, 10, X-Y | |
| Horizontal Bias - Time Base | 0.2us/div ~ 0.2s/div | |
| Horizontal Bias - Sweep Width | ×10 magnification | |
| Horizontal Bias - Accuracy | 3% | |
| Correction Waveform | Frequency: 1KHz 20%, Voltage: 0.5V 1% | |
| Input Impedance | 1MΩ | |
| Physical Dimensions | 450 × 310 × 150 mm | |
| Weight | 8Kg | |
